Performance Comparison of Four Technologies of On-Grid PV Solar Systems under Baghdad Climate during February
Article Sidebar
Main Article Content
Abstract
All solar photovoltaic technologies studied in this research are located in Baghdad city at coordinates (33.33 °N, 44.43 °E, and 41 m above sea level). These technologies are 5 kWp Mono-Si, 107 kWp poly-Si, 15 kWp HIT, and 5 kWp CIGS. CIGS is the second generation while mono, poly, and HIT Si are the first generation. The energy production during February for CIGS, HIT, Mono-Si, and Poly-Si was 642.41 kWh, 1835.2 kWh, 542 kWh and 11174 kWh, respectively. The efficiencies of CIGS, HIT, Mono-Si, and Poly-Si were 12.6%, 14.6%, 10.2%, and 13.2%, respectively. The performance ratio for CIGS, HIT, Mono-Si, and Poly-Si were 83%, 83.3%, 74%, and 75%, respectively.
Downloads
Article Details
This work is licensed under a Creative Commons Attribution 4.0 International License.
How to Cite
References
[1] N. Amin, C. W. Lung, and K. Sopian, “A practical field study of various solar cells on their performance in Malaysia,” Renew. Energy, vol. 34, pp. 1939–1946, 2009, https://doi.org/10.1016/j.renene.2008.12.005.
[2] C. Li, “Comparative performance analysis of grid-connected PV power systems with different PV technologies in the hot summer and cold winter zone,” Int. J. Photoenergy, vol. 2018, Art. no. 8307563, 2018, https://doi.org./10.1155/2018/8307563.
[3] M. Patsalides, D. Evagorou, G. Makrides, Z. Achillides, G. E. Georghiou, A. Stavrou, V. Efthimiou, B. Zinsser, W. Schmitt, and J. H. Werner, “The effect of solar irradiance on the power quality behavior of grid-connected photovoltaic systems,” in Proc. Int. Conf. Renewable Energy and Power Quality (ICREPQ), Seville, Spain, Mar. 2007, https://doi.org/10.53540/tjer.vol19iss2pp140-151.
[4] J. Denz, J. Hepp, C. Buerhop, B. Doll, J. Hauch, C. J. Brabec, and I. M. Peters, “Defects and performance of Si PV modules in the field—An analysis,” Energy Environ. Sci., vol. 15, no. 6, pp. 2180–2199, 2022, https://doi.org/10.1039/D2EE00109H.
[5] B. Marion, J. Adelstein, H. Hayden, B. Hammond, T. Fletcher, B. Canada, D. Shugar, H. Wenger, A. Kimber, L. Mitchell, G. Rich, and T. Townsend, “Performance parameters for grid-connected PV systems,” in Proc. 31st IEEE Photovoltaic Specialists Conf., 2005, pp. 1601–1606, https://doi.org/10.1109/PVSC.2005.1488451.
[6] C. Cañete, J. Carretero, and M. Sidrach-de-Cardona, “Energy performance of different photovoltaic module technologies under outdoor conditions,” Energy, vol. 65, pp. 295–302, 2014, https://doi.org/10.1016/j.energy.2013.12.013.
[7] H. A. Kazem and M. T. Chaichan, “Experimental effect of dust physical properties on photovoltaic module in northern Oman,” Sol. Energy, vol. 139, pp. 68–80, 2016, https://doi.org/10.1016/j.solener.2016.09.019.
[8] R. S. Jawad, K. I. Abass, A. A. Al-Wailie, and S. M. Al-Zubaidi, “Dust effect on PV outcomes at five different sites around Baghdad,” J. Sci. Eng. Res., vol. 4, no. 7, pp. 93–102, 2017. Available: https://www.researchgate.net/search.Search.html?query=Dust+effect+on+PV+outcomes+at+five+different+sites+around+Baghdad&type=publication
[9] M. Adaramola and E. Vignes, “Preliminary assessment of a small-scale rooftop PV grid-tied system in Norwegian climatic conditions,” Energy Convers. Manag., vol. 90, pp. 458–465, 2015, https://doi.org/10.1016/j.enconman.2014.11.028.
[10] N. K. Kasim, H. H. Hussain, and A. N. Abed, “Boosting the energy output of an on-grid solar PV system using novel tech-niques,” J. Appl. Res. Technol., vol. 21, no. 6, pp. 1066–1074, 2023, https://doi.org/10.22201/icat.24486736e.2023.21.6.2036.
[11] N. Abed and N. K. Kasim, “Improving the conversion efficiency and electrical output of a solar PV system by developing and implementing a cooling system,” Therm. Eng. Res., vol. 20, no. 2, pp. 161–171, 2024, https://doi.org/10.53540/tjer.vol20iss2.
[12] N. K. Kasim, H. H. Hussain, and A. N. Abed, “Increasing the power output of a PV solar system by using a cooling-reflector assembly,” Proc. Eng. Technol. Innov., vol. 22, pp. 40–49, Jul. 2022, https://doi.org/10.46604/peti.2022.9976.
[13] N. K. Kasim, H. H. Hussain, and A. N. Abed, “Studying the performance of second-generation PV solar technology under Baghdad climate,” Res. J. Adv. Sci., vol. 1, no. 2, 2020. Available: https://royalliteglobal.com/rjas/article/view/389
[14] A. Raj, M. Gupta, and S. Panda, “Design simulation and performance assessment of yield and loss forecasting for a 100 kWp grid-connected solar PV system,” in Proc. 2nd Int. Conf. Next Generation Computing Technologies (NGCT), Dehradun, India, 2016, pp. 528–533, https://doi.org/10.1109/NGCT.2016.7877472.
[15] H. Rezk, M. R. Gomaa, and M. A. Mohamed, “Energy performance analysis of on-grid solar photovoltaic system—A practical case study,” Int. J. Renew. Energy Res., vol. 9, no. 3, pp. 1292–1301, 2019, https://doi.org/10.20508/ijrer.v9i3.9629.g7706.
